Why choose Avery Dennison RFID?
As the world’s largest UHF RFID partner, we provide solutions
for multiple industries, from retail apparel and food to healthcare
and aviation. Our integrated global RFID approach is proven to
increase inventory accuracy, improve supply chain agility and
enhance visibility across all channels.
When you choose Avery Dennison RFID, you get field-proven inlay
products, advanced research and testing capabilities, experienced
engineering and technical resources, and, most importantly, a
partner with a deep understanding of what it takes to make your
application successful.
Sustainability is at the core of everything we do, from innovation
and product design to development and production. The majority
of our inlays now feature our patented SmartFace™ Technology,
which is one of the most sustainable solutions on the market,
reducing your brand’s environmental impact.
For additional information, please contact:
Telephone 866-903-RFID (7343) / +1-770-965-0807
Email rfid.info@averydennison.com
Applications
} Item-level retail: Apparel, accessories, cosmetics, jewelry,
food and general retail
} Healthcare: Medical and pharmaceutical
} Transportation: Automotive and aviation
} Industrial logistics and manufacturing
} Brand protection and product authentication
} Supply chain, inventory and logistics
} Contactless cards and tickets
} Library, media, documents and files
With Avery Dennison RFID, you get the benefit of our relationships
with best-in-class chip and reader manufacturers, label and tag
converters and systems integrators across the globe. We can
support you with the most challenging RFID projects across all
channels, offering the total solution to meet your business needs.
Emaaaméé
“WWW
mm
HMDIHHHWlEElflflflJ
UHF RFID Inlays
860-960 MHz, ISO-18000-6C, EPC Class 1 Gen 2
NAME DESIGN ANTENNA SIZE CHIP COMMON MARKETS & APPLICATIONS
AD-160
2.36 x 0.16 in
60 x 4 mm
U7
} Cosmetics and other item-level retail
} Personal care products
AD-163 U8
AD-171 1.06 x 0.55 in
27 x 14mm M5 } Apparel and other item-level retail
} Pharmaceutical and healthcare
AD-173 1.06 x 0.55 in
27 x 14mm U8 } Apparel and other item-level retail
} Pharmaceutical and healthcare
AD-172 0.87 x 0.49 in
22 x 12.5 mm U7 } Jewelry
} Supply chain, inventory and logistics
AD-180
1.02 in Diameter
26 mm Diameter U7 } Cosmetics and item-level retail
AD-226 3.74 x 0.32 in
95 x 8.15 mm G2iM
} Apparel and other item-level retail
} Supply chain, inventory and logistics
} Returnable transport units (RTUs)
AD-229 r6-P 3.74 x 0.32 in
95 x 8.15 mm R6/R6-P
AD-236
U7
2.76 x 0.57 in
70 x 14.5 mm U7
} Supply chain, inventory and logistics
} Apparel and other item-level retail
} Home essentials
AD-237 2.76 x 0.57 in
70 x 14.5 mm R6/R6-P
AD-238 2.76 x 0.57 in
70 x 14.5 mm U8
AD-301 1.18 x 0.59 in
30 x 15 mm R6/R6-P } Children accessories
} Fashion jewelry and sunglasses
AD-310 1.63 x 1.14 in
41.4 x 29 mm U8
} Apparel and other item-level retail
} Supply chain, inventory and logistics
} Home essentials
AD-320 ETSI
AD-320 FCC
1.63 x 0.63 in
41.4 x 16 mm
U7
} Supply chain, inventory and logistics
} Apparel and other item-level retail
} Pharmaceutical and healthcare
AD-321 ETSI
AD-321 FCC R6/R6-P
AD-324 ETSI
AD-324 FCC U8
FCC U7
FCC U8
TP1
RF2
TP2
RF1
R6
ETSI U7
E.
NAME DESIGN ANTENNA SIZE CHIP COMMON MARKETS & APPLICATIONS
AD-350 5070-1-1 B
U8
2.99 x 0.236 in
76 x 6 mm U8 } Apparel and other item-level retail
AD-370
2.09 x 0.75 in
53 x 19 mm
U7
} Apparel and other item-level retail
} Also available in narrow-edge leading format
AD-372 U8
AD-373 U7XM } Aviation asset tracking
} Automotive
AD-380
1.97 x 1.18 in
50 x 30 mm
G2iM
} Supply chain, inventory and logistics
} Industrial and automotive
} Apparel and other item-level retail
} Home essentials
} AD-383 is also available in narrow-edge
leading format
AD-383 U7
AD-384 R6/R6-P
AD-385 U8
AD-454
2.75 x 0.75 in
70 x 19 mm
(label dimensions)
R6-P
} Metal and Liquids
} Industrial & Electronics
} Available in label format only
AD-456
2.52 x .0236 in
64 x 6 mm
(label dimensions)
U8
} Metal and Liquids
} Food & Beauty
} Available in label format only
AD-550 1.5 x 2.99 in
38 x 76 mm M5
} Aviation baggage tracking
} Supply chain, inventory and logistics
AD-661
3.55 x 0.75 in
90 x 19 mm
R6/R6-P
} Automotive & glass
} Personal ID Badges & race timing
AD-662 UCODE DNA
AD-663 U7XM/U7XM+
AD-665
U8
U8
AD-680 1.97 x 1.97 in
50 x 50 mm R6/R6-P } Supply chain management
} Package tracking
} Asset tracking
AD-681 1.97 x 1.97 in
50 x 50 mm M4D/M4QT/M4i
AD-806 0.63 x 0.63 in
16 x 16 mm U7
} Healthcare and item-level
} Supply chain, inventory and logistics
AD-810 0.63 in Diameter
16 mm Diameter R6
} Pharmaceutical and healthcare
} Cosmetics and other item-level retail
AD-850 0.406 in Diameter
10.3 mm Diameter M4QT
} Pharmaceutical and healthcare
} Near-field applications
UHF RFID Inlays
800-960 MHz, ISO-18000-6C, EPC Class1 Gen 2
U8
5053-3-1 D M4D
U8
NFC RFID Inlays
13.56 MHz, ISO-14443, Type A
NAME DESIGN SIZE CHIP USER MEMORY COMMON APPLICATIONS
AD-721 0.827 in (diameter)
21 mm (diameter)
NXP
NTAG 213
144 bytes
Read / Write
} Retail environment
} Print media
} Miscellaneous applications
AD-740 1.50 x 0.89 in
38 x 22.5 mm
NXP
Ultralight EV1
384 bit
Read / Write
AD-750 0.709 x 0.315 in
18 x 8 mm
NXP
NTAG 213
144 bytes
Read / Write
HF RFID Inlays
13.56 MHz, ISO-15693, 18000-3 Mode 1
NAME DESIGN SIZE CHIP USER MEMORY COMMON APPLICATIONS
AD-709x 1.85 x 1.85 in
47 x 47 mm
NXP ICODE
SLIX
896 bit EEPROM
Read / Write } Library, media, documents and files
AD-714x 1.77 x 3 in
45 x 76 mm
NXP ICODE
SLIX
896 bit EEPROM
Read / Write
} Contactless cards and tickets
} Library, media, documents and files
AD-730x 1.22 x .55 in
31 x 14 mm
NXP ICODE
SLIX
896 bit EEPROM
Read / Write } Pharmaceutical and healthcare
Auburn University ARC Approved Inlay Designs
Drawings not to scale. The chart contained herein is only intended as a suggestive guide for preliminary
inlay selection. Please refer to www.rfid.averydennison.com for complete terms and conditions, including
warranty terms, relating to this product. You should periodically review the site as terms and conditions
are subject to change without notice.
© 2019 Avery Dennison Corporation. All rights reserved. Avery Dennison
®
is a registered trademark of Avery
Dennison Corporation. Fasson, and all other Avery Dennison brands, product names, antenna designs
and codes or service programs are trademarks of Avery Dennison Corporation. Third party trademarks
and tradenames are used herein and are the property of their respective owners.
MODEL # CAT A
DENIM
CAT B
POLYBAGGED
APPAREL
CAT C
BOXED
ELECTRONICS
CAT D
HANGING
APPAREL
CAT I
DENIM &
POLYBAGGED
APPAREL
(ETSI)
CAT K
SMALL
APPAREL
(ETSI)
SPEC M SPEC F SPEC G SPEC N SPEC Q SPEC U
AD-229r6/r6-P X X X X X X X X X X X
AD-236u7 X X X X X X X X X X X
AD-237r6/r6-P X X X X X X X X X X X
AD-238u8 X X X X X X X X X X X
AD-301r6/r6-P X
AD-310u8 X X X X X X X X X X
AD-320u7 X X X X X X
AD-321r6/r6-P X X X X X X
AD-324u8 X X X X X X X X
AD-370u7 X X X X
AD-372u8 X X X X X X X X X
AD-383u7 X X X X X X X X X X
AD-384r6/r6-P X X X X X X X X X X X
AD-385u8 X X X X X X X X X X X
AD-550m5 X
Avery Dennison RFID
Americas / Europe / Asia Pacific
866-903-RFID (7343) / +1-770-965-0807
rfid.info@averydennison.com
averydennison.com/RFID
UHF IC Memory
NAME EPC MEMORY USER MEMORY TID MEMORY
M4D Impinj® Monza® 4D 128-bit 32-bit 48-bit unique serialized TID number
M4i Impinj® Monza® 4i 256-bit 480-bit 48-bit unique serialized TID number
M4QT Impinj® Monza® 4QT 128-bit 512-bit 48-bit unique serialized TID number
M5 Impinj® Monza® 5 128-bit 32-bit 48-bit unique serialized TID number
R6 Impinj® Monza® R6 96-bit 0 48-bit unique serialized TID number
R6-P Impinj® Monza® R6-P 96 /128-bit 64/ 32-bit 48-bit unique serialized TID number
G2iM NXP G2iM 256-bit 512-bit 48-bit unique serialized TID number
U7 NXP UCODE 7 128-bit 0 48-bit unique serialized TID number
U7XM NXP UCODE 7XM 448-bit 2K-bit 48-bit unique serialized TID number
U7XM+ NXP UCODE 7XM+ 448-bit 2K-bit 48-bit unique serialized TID number
U8 NXP UCODE 8 128-bit 0 48-bit unique serialized TID number
DNA NXP UCODE DNA 224-bit 3K-bit 48-bit unique serialized TID number
